ODM 110V Single Phase Online UPS 1-3KVA Manufacturer, Factory

Model: Winwin series 1-3KVA (1-1Phase)

REO Power Winwin series of 1K -3KVA with 110V input and 110V output single phase online UPS, provides continuous power backup, protecting devices from outages, surges, and fluctuations. Ideal for critical equipment like servers, it ensures seamless operation. With high reliability, advanced safety features, and stable performance, it safeguards sensitive electronics, making it a trusted choice for both home and office use.

Send Inquiry

Product Description

Key Features

✓ High-frequency online double conversion

✓ DSP-controlled technology

✓ Active PFC, input PF > 0.99

✓ Battery-free startup capability

✓ Wide input voltage range: 55~145VAC

✓ Generator-compatible design

✓ Cold start and ECO mode supported

✓ Auto-sensing 50Hz/60Hz frequency

✓ Supports laser printers & ultrasound systems

✓ Communication: RS232, USB, SNMP (Optional)

Technical Specification

Model	1K	1KL	2K	2KL	3K	3KL
Capacity	1KVA/1KW		2KVA/2KW		3KVA/3KW
AC INPUT
Rated Voltage	110/115/120/127VAC
Voltage Range	55~145VAC
Frequency Range	40Hz~70Hz
Input Power Factor	≥0.99
AC OUTPUT
Output Voltage	110/115/120/127VAC
Waveform	Pure Sine Wave
Power Factor	1.0
Overload Capability	105%~130% for 60s; 130%~150% for 10s
BATTERY & CHARGER
Rated Voltage	24VDC	36VDC	48VDC	72VDC	72VDC	72VDC
Backup Time	>6mins @ half load (Standard Models)
PHYSICAL
Dimension (WxDxH)	144x358x224 mm		190x380x323 mm		190x380x323 mm

* Product specifications are subject to change without prior notice.
* Model with "L" means long backup time model (external battery).

Production Showcase

Professional Packaging

Frequently Asked Questions

1. What is the warranty period for your UPS products?

We offer a standard 2-year warranty (after shipping) on our UPS systems.

2. Do you provide international shipping?

Yes, we ship our products globally. We can offer shipping services as per your specific request.

3. Can the UPS be mounted on a rack?

Yes, certain rack models are specifically designed for rack mounting applications.

4. What is the efficiency rating of your UPS systems?

Our single-phase UPS systems have an efficiency rating of up to 90%. Three-phase and modular UPS efficiency can reach up to 96%.

5. What is the operating temperature range for your UPS?

The operating temperature range is typically 0~40°C for indoor UPS. Outdoor units with air conditioning can operate from -40°C to 55°C.

6. Do you guarantee safe and secure delivery of products?

Yes, we use high-quality export packaging. For container orders, we provide excellent protection. We also recommend palletizing based on standard quantities to ensure safety.
